CP PLUS 4PORT POE FULL GIGA CP-DNW-GPU4G2-48C

The CP PLUS CP-DNW-GPU4G2-48C 6-Port Gigabit Unmanaged PoE Switch is designed to provide reliable network connectivity and power distribution for IP surveillance and other PoE-enabled devices. It combines four Gigabit PoE ports with two dedicated Gigabit uplink ports, allowing connected cameras and other PoE devices to receive both data and power through a single Ethernet cable.

The four 10/100/1000 Mbps PoE ports support IEEE 802.3af and IEEE 802.3at standards and can deliver up to 30W per PoE port. The switch provides a total 48W PoE power budget, making it suitable for connecting multiple compatible IP cameras, access points and other PoE devices.

For network connectivity and expansion, the switch includes two 1000 Mbps Gigabit uplink ports. It offers a 12 Gbps full-duplex switching capacity and a 1.488 Mpps packet forwarding rate per port, supporting efficient data transfer across the network.

The switch features VLAN mode to help isolate network traffic and includes PoE Watchdog functionality for monitoring connected PoE devices. If a compatible PoE device becomes unresponsive, the Watchdog feature can help maintain network availability.

For long-distance CCTV deployments, Extend mode allows Ports 3–4 to transmit up to 250 meters at 10Mbps using Cat5e or higher cable. In standard mode, transmission can reach up to 100 meters at 1000Mbps.

The CP-DNW-GPU4G2-48C uses a store-and-forward architecture, supports Auto MDI/MDIX and includes surge and ESD protection. Its compact desktop design and plug-and-play operation make it convenient for CCTV installations in homes, offices, shops and small commercial environments.

Technical Specifications

Suitable Applications

• IP CCTV camera installations
• Home surveillance systems
• Small office networks
• Retail and shop surveillance
• Commercial security systems
• IP camera networks
• PoE access point installations
• Small business networking
• Long-distance CCTV deployments
