PeopleLink AILive Board Plus X86 – 86-Inch 4K UHD Interactive Flat Panel

PeopleLink AILive Board Plus X86

The PeopleLink AILive Board Plus X86 Interactive Flat Panel brings large-screen visualisation and interactive touch technology to modern educational and professional environments. Its 86-inch 4K UHD display provides ample workspace for presenting information, annotating documents, explaining concepts and collaborating with multiple participants.

Large 86-Inch 4K UHD Display

The 3840 × 2160 resolution delivers detailed visuals for presentations, diagrams, spreadsheets, educational material and business content. The 16:9 display features DLED backlighting, brightness of up to 450 cd/m² and a 1200:1 contrast ratio. Zero-bonding technology and 4mm tempered anti-glare glass support a practical interactive viewing and writing experience.

Multi-Touch Interactive Experience

The infrared touch system supports up to 40 touch points, enabling multiple participants to interact with the display simultaneously. With a touch response time of up to 5ms and specified accuracy of ±2mm, users can write, draw, annotate and navigate compatible content. A passive stylus supports a two-colour writing mode for explanations, brainstorming and collaborative lessons.

Android 14 and Integrated Hardware

Powered by Android 14, an octa-core ARM Cortex-A55 processor and a quad-core Mali-G52 GPU, the panel provides an integrated platform for compatible applications and everyday interactive tasks. Its 8GB RAM and 128GB internal storage support installed applications and locally stored content.

Integrated Audio and Wireless Connectivity

The built-in dual 20W speakers provide audio for presentations, classroom activities and meetings. Wi-Fi 5 enables wireless network connectivity, while Bluetooth 5 supports compatible wireless peripherals. These integrated capabilities help simplify everyday use in classrooms, conference rooms and shared workspaces.

Multiple Connectivity Options

The panel includes HDMI, USB 3.0, USB 2.0, touch USB, USB Type-C for data, VGA, RS232, LAN input and audio interfaces. Additional connections, such as HDMI output, DisplayPort input, LAN output and microphone input, are available through optional interface configurations. Confirm the exact ports supplied with the selected unit before purchase.

Smart Management and Security

Useful management features include screen locking, USB locking, touch locking, scheduled power switching and energy-saving mode. RS232 central control supports integration with compatible control and management systems, making the panel suitable for shared institutional and corporate environments.

Optional AI Camera and Microphone

An optional 48MP camera supports voice tracking, face tracking and AI gesture control. An optional eight-microphone array provides pickup from up to 8 metres and supports echo cancellation, background-noise suppression and gain compensation. These features are configuration-dependent and may need to be ordered separately.

The PeopleLink AILive Board Plus X86 is suitable for schools, colleges, universities, corporate offices, conference rooms, training centres and other environments requiring a large interactive display for communication, teaching and collaborative work.

Technical Specifications
