ViewSonic ViewBoard IN6504V-N 4K Interactive Display

The ViewSonic ViewBoard IN6504V-N 65-inch 4K Interactive Display is designed to support interactive teaching, presentations, meetings and collaborative work in education and business environments. Its large 65-inch UHD display with 3840 × 2160 resolution provides detailed visuals, while the HVA panel delivers a 178° viewing angle and a 5000:1 typical contrast ratio. The 450-nit display also features a 9H anti-glare surface for use in interactive environments.

The display uses Ultra Fine Touch Technology with IR recognition, supporting up to 40 simultaneous touch points on both Windows and Android. Palm rejection helps provide a more natural writing experience, while the high touch resolution supports precise interaction with digital content. Dual-pen functionality allows users to work with two pens and switch between writing styles.

For meetings and hybrid collaboration, the ViewBoard includes a built-in 50MP 4K camera and 8-array microphone. The camera supports features such as auto-framing and face and voice tracking, while the integrated microphone array is designed to provide clear voice pickup without requiring separate camera and microphone hardware. Built-in 20W × 2 speakers provide audio directly from the display.

The IN6504V-N runs on Android 14 with Google EDLA certification and is upgradeable to Android 16. EDLA provides access to Google applications and services, including the Google Play Store and Google Workspace. The display is powered by an octa-core processor with 8GB RAM and 128GB storage, giving users an integrated platform for applications, presentations and interactive content.

An integrated NFC reader enables quick access to personalized settings and user profiles. This can be useful in shared classroom and meeting-room environments where multiple users need to access their own workspace without repeatedly configuring the display.

The display also includes AI-assisted interactive tools. The Text Recognition Pen can convert handwritten or printed content into editable digital text and supports functions such as translation and text-to-speech. The Magical Pen can transform sketches into detailed visuals, while Shape Recognition helps turn hand-drawn shapes into cleaner digital forms.

For connectivity, the ViewBoard provides two HDMI inputs supporting 4K at 60Hz, one HDMI output, three USB-A ports, two USB-B touch ports and two USB-C ports. It also includes Gigabit RJ45 LAN, RS232, a MicroSD/TF card slot, audio input, line-out and optical SPDIF output. An optional Intel Standard OPS slot is available for compatible PC modules.

Highlights / Key Features

• 65-inch 4K UHD interactive display
• 3840 × 2160 UHD resolution
• HVA panel with DLED backlight
• 450 nits typical brightness
• 5000:1 typical contrast ratio
• 6.5ms response time
• 178° horizontal and vertical viewing angles
• 1.07 billion colors
• 9H anti-glare surface
• Zero Bonding technology
• Ultra Fine Touch Technology with IR recognition
• Up to 40 touch points on Windows and Android
• Palm rejection support
• 32768 × 32768 touch resolution
• Built-in 50MP 4K camera
• Auto-framing, face and voice tracking
• Built-in 8-array microphone
• Dual 20W speakers
• Google EDLA certified
• Android 14 platform, upgradeable to Android 16
• Google Play Store and Google Workspace access
• Octa-Core processor
• 8GB RAM and 128GB storage
• Built-in Wi-Fi
• NFC reader for quick sign-in and personalized settings
• AI-powered learning and collaboration tools
• Text Recognition Pen with translation and text-to-speech support
• Magical Pen for AI-powered image generation
• Shape Recognition for refining hand-drawn shapes
• 2 × HDMI inputs supporting up to 4K@60Hz
• 1 × HDMI output
• 2 × USB-C ports
• 3 × USB-A ports
• 2 × USB-B touch ports
• RJ45 Gigabit LAN
• RS232 connectivity
• MicroSD/TF card slot
• Optical SPDIF output
• 500 × 400mm VESA wall-mount support

Specifications

Specifications are based on ViewSonic India’s official product page and datasheet.

What’s in the Box

• Power Cord – 3m
• HDMI Cable – 3m
• USB Touch Cable – 3m, USB 2.0
• 2 × Touch Pens
• Remote Control
• 2 × AAA Batteries
• Quick Start Guide with Compliance Statement
• 4 × Wall-Mount Screws
• NFC Card
