PeopleLink MCC DSP 200W – Digital Signal Processor with 200W Amplifier
Original price was: ₹231,000.00.₹135,482.00Current price is: ₹135,482.00.
PeopleLink MCC DSP 200W is a digital signal processing and amplification solution designed for classroom audio, training rooms, meeting spaces and professional conferencing environments. It combines a Class-D amplifier with digital audio processing features, including automatic echo cancellation, automatic gain control and dynamic noise reduction.
Out of stock
PeopleLink MCC DSP 200W
The PeopleLink MCC DSP 200W combines digital signal processing and audio amplification in a rack-mountable solution for professional audio and conferencing applications. Designed for environments such as classrooms, training rooms and meeting spaces, it supports voice reinforcement and integration with compatible microphones, speakers and audio equipment.
Integrated DSP and Amplification
The system combines audio processing with a Class-D stereo amplifier rated at 200W RMS, specified as 2 × 100W at 8Ω under the stated operating conditions. This integrated design helps simplify audio system installation by bringing key processing and amplification functions into one unit.
Audio Processing for Speech Clarity
Built-in digital signal processing features include automatic echo cancellation, automatic gain control, dynamic noise reduction and noise suppression. These functions help improve speech intelligibility and support more effective communication in suitable room and equipment configurations.
Flexible Microphone Connectivity
The unit provides microphone input options for compatible audio setups. Connections include an unbalanced 6.5mm microphone input with gain control and two balanced microphone inputs with 48V/12V phantom power support, using the connectors specified for the relevant model revision. Separate gain controls help users adjust input levels.
Audio and Control Interfaces
RCA line input and output connections support integration with compatible audio sources and equipment. A USB 2.0 interface supports PC connectivity, while RS-232 provides a control interface for compatible systems. The exact connector layout should be checked against the version supplied.
Wireless Microphone Options
The MCC DSP product family is offered with wireless microphone configurations, which may include handheld and headband/lapel microphone combinations. Wireless frequency selection, operating range and included microphones depend on the specific package and hardware revision. Confirm the supplied configuration before purchase.
Rack-Mountable Installation
The rack-mountable chassis is designed for integration into professional AV installations. The system is suitable for classrooms, training rooms, conference facilities and other spaces requiring speech reinforcement and integrated audio processing.
Technical Specifications
| Specification | Details |
|---|---|
| Brand | PeopleLink |
| Product Name | MCC DSP 200W |
| Product Type | Digital Signal Processor with Amplifier |
| Amplifier Type | Class-D (Digital) |
| Channel Configuration | 2-channel stereo |
| Rated RMS Output Power | 200W total |
| Output Power at 8Ω | 2 × 100W, under specified operating conditions |
| Minimum Speaker Impedance | Confirm the applicable rating for the supplied revision |
| Amplifier Frequency Response | 20Hz–20kHz |
| DSP Frequency Range | 30Hz–16kHz |
| Automatic Echo Cancellation | Yes |
| Automatic Gain Control | Yes |
| Dynamic Noise Reduction | Yes |
| Noise Suppression | Yes, as listed in the applicable datasheet |
| Full-Duplex Audio | Yes |
| Unbalanced Microphone Input | 1 × 6.5mm phono jack with gain control |
| Balanced Microphone Inputs | 2 × balanced inputs with 48V/12V phantom power support |
| Line Input | 1 × stereo RCA |
| Line Output | 1 × stereo RCA |
| PC Connectivity | 1 × USB 2.0 |
| Control Interface | 1 × RS-232 |
| Wireless Microphone Type | UHF, where included in the selected package |
| Wireless Microphone Options | Depends on package configuration |
| Wireless Operating Range | Depends on hardware revision and operating conditions |
| Microphone Frequency Response | 80Hz–18kHz, for the listed wireless microphone system |
| Chassis | Rack-mountable |
| Power Supply Protection | Short-circuit, overload and over-voltage protection, as specified |
| Applications | Classrooms, training rooms, meeting rooms and audio-conferencing installations |
