Camera:-
- Image Sensor: 1/2.7″ Progressive scan CMOS
- Min. Illumination: 0.01lux(Color), 0lux(IR on)
- Shutter Time: Auto/Manual, 1/3~1/10000s
- Lens: 3.6 mm@F2.0: horizontal FOV: 88°, vertical FOV:47°
- Lens Mount: M12
- Day/Night: IR cut filter with auto switch
- Wide Dynamic Range: DWDR
- Max. IR LEDs Length: 30M
- Smart IR: Support
Compression:-
- Video Compression: H.264/H.264+/H.265/H.265+
- H.264 Codec profile: Base/Main/High profile
- H.265 Codec profile: Main profile
- Video Bit Rate: 11 Kbps~8 Mbps
Image:-
- Max.resolution: 1920 × 1080
- Main Stream: 50Hz:25fps 1080P(1920 × 1080) 25fps 960P(1280 × 960),25fps 720P(1280 × 720) 60Hz:30fps 1080P(1920 × 1080) 30fps 960P(1280 × 960),30fps 720P(1280 × 720)
- Sub Stream: 50Hz:25fps D1(704 × 576),25fps CIF(352 × 288) 60Hz:30fps D1(704 × 480),30fps CIF(352 × 240)
- Mobile Stream: 50Hz:25fps CIF(352 × 288)60Hz:30fps CIF(352 × 240)
- Image Setting: Brightness/Contrast/Saturation/Hue/Sharpness
- BLC: Support
- HLC: Support
- ROI: Support
- Defog: Support
- Event: Motion Detection, Video Shelter
- Smart Functions: Area Intrusion, Line crossing, Object Missing, Unattended Object, Fast Moving
Network:-
- Protocols: TCP/IP,ICMP,HTTP,HTTPS,DHCP,DNS,DDNS,RTP,RTSP,RTCP, NTP,IGMP,UPnP,SMTP,SNMP,UPnP-TM,P2P,Bonjour
- System compatibility: Onvif 2.6, Profile S, CGI
- Security: User authentication, IP address filtering, Video mask
- Mobile Surveillance: iPhone, iPad, Android devices
- Communication interface: 1 RJ45 10M / 100M Ethernet Port
